Vgate vLinker FD WiFi OBD2 Diagnostic Tool for iOS, Android and Windows - Support Medium Speed CAN(MS-CAN)
Tips: Support OEM
Vgate vLinker FD for WIFI is a diagnostic scan tool, trip computer, logger, and real-time performance monitor.
1. Transform your iOS(BLE), Android device, or Windows PC into a professional-grade diagnostic scan tool.
2. Vgate vLinker FD WiFi OBD-II adapter provides access to MS-CAN networks in addition to the 5 legislated OBD-II protocols.
3. Work with iOS, Android & Windows.
4. Fully compatible with ELM's AT command set (ELM327, ELM329)
5. Fully compatible with STN's ST command set
6. This pocket-size adapter won't obstruct driver legroom and features unparalleled performance, intelligent sleep mode, exceptional third party app support.
Hardware Upgrade
Wider Car Compatibility
1. Vgate vLinker FD WiFi works with all 1996 and newer 12V petrol cars compatible with standard OBD2 protocols, and all 1996 and newer 12V small diesel vehicles with a load of 6.5T or less supporting the OBD2 protocols.
2. Do not use on a 24V power diesel car.
3.The vLinker FD WiFi proprietary connection algorithm enables FD to connect to more makes and models than any other scan tool. It also provides access to MS-CAN networks in addition to all legislated OBD-II protocols.
More Mainstream Apps
1.APPs: TORQUE Lite/Pro, FORScan Lite, JScan, OBD Fusion, DashCommand, Car Scanner ELM OBD2, BimmerCode, inCarDoc, Dr.Prius, etc.
2.There are more apps waiting to be explored. Works with more 3rd party apps & software than any other adapter.
BatterySaver Technology
1. Thanks to the unique BatterySaver technology you can rest assured that, unlike other OBD adapters, Vgate vLinker FD WiFi won't drain your battery if you leave it plugged in.
2.Operating Current is 62 mA, automatic sleep in idle state, sleep current is as low as 3mA.
Vgate vLinker FD WiFi Connection Steps - For Android
Android & iOS Device - For detailed steps, please refer to the instruction manual carefully to avoid operating errors.
# Android System Operation Steps **
1. Insert the product into the OBD interface of the car.
2. Turn ignition to Key On Engine Off Position.
3. Turn on Wi-Fi on the phone.
4. Search for the device name "vLinker FD" and connect.
5. Note: You need to click "Decline" when your phone displays the prompt as in Step 5. Otherwise the connection will fail. (You can not use network when connect Wi-Fi.)
6. If the connection is successful, you can open the APP to set up the connection.
# iOS System Operation Steps **
1. Plug the product into the OBD2 interface of the car.
2. Turn ignition to Key On Engine Off Position.
3. Turn on WLAN on the phone.
4. Search for the device name "vLinker FD" and connect.
5. If the connection is successful, you can open the APP to set up the connection.
* NOTE: In the steps of APP operation, since different APPs have different setting and connection steps, please operate according to the relevant information on the APP's official website.
1 x Vgate vLinker FD WIFI
1 x User manual
